• General Information

    Equipment supplied without plug

  • Technical Data

    Code: CLL001V0001

    Model: TC100

    Width | mm: 1150

    Depth | mm: 805

    Height | mm: 1435

    Basket(s): 500x500mm

    Weight | Kg: 210

    Power: 16430W

    Tension | Freq.: 400V | 50Hz

    Consumption: 165Lts/h

    Productivity: 63/95 Basket/h

    Programs | Phases: Washing + Rinse

    Height Wash: 440mm

  • Shipping Information

    Load Capacity (unit):

    TIR | 20” | 40”

  • Other information

    • Left to right operation
    • Other configuration on request
    • With electromechanical control panel
    • Stainless steel AISI 304 construction
    • Smooth doors to prevent residue buildup, double-walled doors that provide good insulation, reducing energy loss and noise
    • The different work zones are controlled by the auto-star and economic rising system, which activate as the baskets pass and deactivate automatically when finished
    • PREWASH it is the first module of the machine where the dishes come into contact with the water. Dirt is softened, preventing residue settling. This allows the following modules to keep the water cleaner, enhancing cleaning and improving the machine’s overall production capacity
    • WASHING, module where the dishes are completely degreased with the combined action of high temperature water and detergent. Wrapped arms ensure all loading areas are reached, removing any food waste
    • RINSING is the process that removes detergent from the dishes. The rinsing arms cover all the dishes with high temperature water, completing the hygiene process In the TC version, washing and rinsing are interconnected in the same module
    • DRYER: Drying achieved through a continuous flow of hot, dry air that evaporates residual drops on the dishes. Power sized to minimize fluctuations while maintaining a constant temperature between 60°C and 70°C, maximizing drying quality.
